SOLARIS

 Passive HOUSE Certified Windows + Patio Doors




The Solaris line of windows and doors is our Passive House certified system approved by the German Passive House Institute (PHI) and Passive House Institute of Canada making the Solaris line our most energy efficient line.

All products are custom-made to order. Contact us for more information on pricing and lead times.

    • Aluminum vinyl hybrid windows

    • 3 1/2” thickness

    • 7 chambers

    • HFL (Holz Fenster) German welding technology

    • Multi point locking system with high strength hardware

    • Double or Triple pane low E insulating glass with 95% argon filled super spacer

    • Triple rubber sealing system with 15mm overlap

    • Customized interior and exterior colours

    • Scratch resistant wood grain foil inside

    • Powder coated aluminum cladding outside

    • High reduction of outsourced noise

    • Hidden hardware

    • Stop flow-backward water drainage wings

    • 20 year service life guarantee

    • 3 year installation guarantee

    • Class CW PG30: Size tested 48.0 x 71.0 in Type DAW (Dual-action Window)

    • Class CW PG1440 (SI): Size tested 1219 x 1803 mm Type DAW (Dual-action Window)

    • Positive Design Pressure (DP) = 1440 Pa (30.1 psf)

    • Negative Design Pressure (DP) = -1440 Pa (-30.1 psf)

    • Water Penetration Resistance Test Pressure = 220 Pa (4.50 psf)

    • Canadian Air Infiltration / Exfiltration = A2 Level

    • High thermal efficiency Uv= 0.78 W/m2K – 0.97 W/m²K
